深入理解GCD

shsY4J

队列

在GCD中包含了四种队列 ： 主队列、 全局队列、 管理队列、自定义队列。这里我们一一来看，其中的实现逻辑。

自定义队列

队列底层使用dispatch_queue_create进行创建

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
dispatch_queue_t
dispatch_queue_create(const char *label, dispatch_queue_attr_t attr)
{
	return _dispatch_lane_create_with_target(label, attr,
			DISPATCH_TARGET_QUEUE_DEFAULT, true);
}


----------------------------------------

//  dispatch_queue_t tq 目标队列，队列中实际的任务在target queue 中执行，这里默认传 DISPATCH_TARGET_QUEUE_DEFAULT - NULL
// dispatch_queue_attr_t 队列属性
// 从参数中获取qos属性
DISPATCH_NOINLINE
static dispatch_queue_t
_dispatch_lane_create_with_target(const char *label, dispatch_queue_attr_t dqa,
		dispatch_queue_t tq, bool legacy)
{
	// 获取队列属性信息
	// dispatch_queue_attr_info_s
	// typedef struct dispatch_queue_attr_info_s {
	// dispatch_qos_t dqai_qos : 8;
	// int      dqai_relpri : 8;
	// uint16_t dqai_overcommit:2;
	// uint16_t dqai_autorelease_frequency:2;
	// uint16_t dqai_concurrent:1;
	// uint16_t dqai_inactive:1;	// } dispatch_queue_attr_info_t;

	dispatch_queue_attr_info_t dqai = _dispatch_queue_attr_to_info(dqa);

	//
	// Step 1: Normalize arguments (qos, overcommit, tq)
	//
	// 获取队列的qos信息
	dispatch_qos_t qos = dqai.dqai_qos;
	//
#if !HAVE_PTHREAD_WORKQUEUE_QOS
	if (qos == DISPATCH_QOS_USER_INTERACTIVE) {
		dqai.dqai_qos = qos = DISPATCH_QOS_USER_INITIATED;
	}
	if (qos == DISPATCH_QOS_MAINTENANCE) {
		dqai.dqai_qos = qos = DISPATCH_QOS_BACKGROUND;
	}
#endif // !HAVE_PTHREAD_WORKQUEUE_QOS

	// overcommit信息
	_dispatch_queue_attr_overcommit_t overcommit = dqai.dqai_overcommit;
	// 如果没有overcommit信息 且 有 targetqueue
	if (overcommit != _dispatch_queue_attr_overcommit_unspecified && tq) {
		// 不能同时指定 overcommit 信息 和 非全局targetqueue
		if (tq->do_targetq) {
			DISPATCH_CLIENT_CRASH(tq, "Cannot specify both overcommit and "
					"a non-global target queue");
		}
	}


	if (tq && dx_type(tq) == DISPATCH_QUEUE_GLOBAL_ROOT_TYPE) {
		// Handle discrepancies between attr and target queue, attributes win
		if (overcommit == _dispatch_queue_attr_overcommit_unspecified) {
			if (tq->dq_priority & DISPATCH_PRIORITY_FLAG_OVERCOMMIT) {
				overcommit = _dispatch_queue_attr_overcommit_enabled;
			} else {
				overcommit = _dispatch_queue_attr_overcommit_disabled;
			}
		}
		if (qos == DISPATCH_QOS_UNSPECIFIED) {
			qos = _dispatch_priority_qos(tq->dq_priority);
		}
		tq = NULL;
	} else if (tq && !tq->do_targetq) {
		// target 是 pthread 或者runloop的root queue  ，设置QOS 或者 overcommit 是不允许的
		// target is a pthread or runloop root queue, setting QoS or overcommit
		// is disallowed
		if (overcommit != _dispatch_queue_attr_overcommit_unspecified) {
			DISPATCH_CLIENT_CRASH(tq, "Cannot specify an overcommit attribute "
					"and use this kind of target queue");
		}
	} else {
		if (overcommit == _dispatch_queue_attr_overcommit_unspecified) {
			// Serial queues default to overcommit!
			// 串行队列的overcommit 是 启用的
			overcommit = dqai.dqai_concurrent ?
					_dispatch_queue_attr_overcommit_disabled :
					_dispatch_queue_attr_overcommit_enabled;
		}
	}
	// 如果没有target queue， 设置获取从root queue 中去获取
	if (!tq) {
		// 获取root queue
		tq = _dispatch_get_root_queue(
				qos == DISPATCH_QOS_UNSPECIFIED ? DISPATCH_QOS_DEFAULT : qos,
				overcommit == _dispatch_queue_attr_overcommit_enabled)->_as_dq;
		if (unlikely(!tq)) {
			DISPATCH_CLIENT_CRASH(qos, "Invalid queue attribute");
		}
	}

	//
	// Step 2: Initialize the queue
	//

	if (legacy) {
		// if any of these attributes is specified, use non legacy classes
		if (dqai.dqai_inactive || dqai.dqai_autorelease_frequency) {
			legacy = false;
		}
	}

	const void *vtable;
	dispatch_queue_flags_t dqf = legacy ? DQF_MUTABLE : 0;
	//
	if (dqai.dqai_concurrent) {
		vtable = DISPATCH_VTABLE(queue_concurrent);
	} else {
		vtable = DISPATCH_VTABLE(queue_serial);
	}


	// auto relase
	switch (dqai.dqai_autorelease_frequency) {
	case DISPATCH_AUTORELEASE_FREQUENCY_NEVER:
		dqf |= DQF_AUTORELEASE_NEVER;
		break;
	case DISPATCH_AUTORELEASE_FREQUENCY_WORK_ITEM:
		dqf |= DQF_AUTORELEASE_ALWAYS;
		break;
	}


	if (label) {
		const char *tmp = _dispatch_strdup_if_mutable(label);
		if (tmp != label) {
			dqf |= DQF_LABEL_NEEDS_FREE;
			label = tmp;
		}
	}

	dispatch_lane_t dq = _dispatch_object_alloc(vtable,
			sizeof(struct dispatch_lane_s));
	_dispatch_queue_init(dq, dqf, dqai.dqai_concurrent ?
			DISPATCH_QUEUE_WIDTH_MAX : 1, DISPATCH_QUEUE_ROLE_INNER |
			(dqai.dqai_inactive ? DISPATCH_QUEUE_INACTIVE : 0));

	dq->dq_label = label;
	dq->dq_priority = _dispatch_priority_make((dispatch_qos_t)dqai.dqai_qos,
			dqai.dqai_relpri);
	if (overcommit == _dispatch_queue_attr_overcommit_enabled) {
		dq->dq_priority |= DISPATCH_PRIORITY_FLAG_OVERCOMMIT;
	}
	if (!dqai.dqai_inactive) {
		// 从target 继承优先级
		_dispatch_queue_priority_inherit_from_target(dq, tq);
		_dispatch_lane_inherit_wlh_from_target(dq, tq);
	}

	_dispatch_retain(tq);
	dq->do_targetq = tq;
	_dispatch_object_debug(dq, "%s", __func__);
	return _dispatch_trace_queue_create(dq)._dq;
}

全局队列 - dispatch_get_global_queue

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
dispatch_queue_global_t
dispatch_get_global_queue(long priority, unsigned long flags)
{
	dispatch_assert(countof(_dispatch_root_queues) ==
			DISPATCH_ROOT_QUEUE_COUNT);

	if (flags & ~(unsigned long)DISPATCH_QUEUE_OVERCOMMIT) {
		return DISPATCH_BAD_INPUT;
	}
	dispatch_qos_t qos = _dispatch_qos_from_queue_priority(priority);
#if !HAVE_PTHREAD_WORKQUEUE_QOS
	if (qos == QOS_CLASS_MAINTENANCE) {
		qos = DISPATCH_QOS_BACKGROUND;
	} else if (qos == QOS_CLASS_USER_INTERACTIVE) {
		qos = DISPATCH_QOS_USER_INITIATED;
	}
#endif
	if (qos == DISPATCH_QOS_UNSPECIFIED) {
		return DISPATCH_BAD_INPUT;
	}
	return _dispatch_get_root_queue(qos, flags & DISPATCH_QUEUE_OVERCOMMIT);
}

这里我们可以看到全局队列最终调用的是_dispatch_get_root_queue

1
2
3
4
5
6
7
8
9
DISPATCH_ALWAYS_INLINE DISPATCH_CONST
static inline dispatch_queue_global_t
_dispatch_get_root_queue(dispatch_qos_t qos, bool overcommit)
{
	if (unlikely(qos < DISPATCH_QOS_MIN || qos > DISPATCH_QOS_MAX)) {
		DISPATCH_CLIENT_CRASH(qos, "Corrupted priority");
	}
	return &_dispatch_root_queues[2 * (qos - 1) + overcommit];
}

实际上_dispatch_root_queuess是一个系统硬编码的队列数组

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
struct dispatch_queue_global_s _dispatch_root_queues[] = {
#define _DISPATCH_ROOT_QUEUE_IDX(n, flags) \
		((flags & DISPATCH_PRIORITY_FLAG_OVERCOMMIT) ? \
		DISPATCH_ROOT_QUEUE_IDX_##n##_QOS_OVERCOMMIT : \
		DISPATCH_ROOT_QUEUE_IDX_##n##_QOS)
#define _DISPATCH_ROOT_QUEUE_ENTRY(n, flags, ...) \
	[_DISPATCH_ROOT_QUEUE_IDX(n, flags)] = { \
		DISPATCH_GLOBAL_OBJECT_HEADER(queue_global), \
		.dq_state = DISPATCH_ROOT_QUEUE_STATE_INIT_VALUE, \
		.do_ctxt = _dispatch_root_queue_ctxt(_DISPATCH_ROOT_QUEUE_IDX(n, flags)), \
		.dq_atomic_flags = DQF_WIDTH(DISPATCH_QUEUE_WIDTH_POOL), \
		.dq_priority = flags | ((flags & DISPATCH_PRIORITY_FLAG_FALLBACK) ? \
				_dispatch_priority_make_fallback(DISPATCH_QOS_##n) : \
				_dispatch_priority_make(DISPATCH_QOS_##n, 0)), \
		__VA_ARGS__ \
	}
	_DISPATCH_ROOT_QUEUE_ENTRY(MAINTENANCE, 0,
		.dq_label = "com.apple.root.maintenance-qos",
		.dq_serialnum = 4,
	),
	_DISPATCH_ROOT_QUEUE_ENTRY(MAINTENANCE, DISPATCH_PRIORITY_FLAG_OVERCOMMIT,
		.dq_label = "com.apple.root.maintenance-qos.overcommit",
		.dq_serialnum = 5,
	),
	_DISPATCH_ROOT_QUEUE_ENTRY(BACKGROUND, 0,
		.dq_label = "com.apple.root.background-qos",
		.dq_serialnum = 6,
	),
	_DISPATCH_ROOT_QUEUE_ENTRY(BACKGROUND, DISPATCH_PRIORITY_FLAG_OVERCOMMIT,
		.dq_label = "com.apple.root.background-qos.overcommit",
		.dq_serialnum = 7,
	),
	_DISPATCH_ROOT_QUEUE_ENTRY(UTILITY, 0,
		.dq_label = "com.apple.root.utility-qos",
		.dq_serialnum = 8,
	),
	_DISPATCH_ROOT_QUEUE_ENTRY(UTILITY, DISPATCH_PRIORITY_FLAG_OVERCOMMIT,
		.dq_label = "com.apple.root.utility-qos.overcommit",
		.dq_serialnum = 9,
	),
	_DISPATCH_ROOT_QUEUE_ENTRY(DEFAULT, DISPATCH_PRIORITY_FLAG_FALLBACK,
		.dq_label = "com.apple.root.default-qos",
		.dq_serialnum = 10,
	),
	_DISPATCH_ROOT_QUEUE_ENTRY(DEFAULT,
			DISPATCH_PRIORITY_FLAG_FALLBACK | DISPATCH_PRIORITY_FLAG_OVERCOMMIT,
		.dq_label = "com.apple.root.default-qos.overcommit",
		.dq_serialnum = 11,
	),
	_DISPATCH_ROOT_QUEUE_ENTRY(USER_INITIATED, 0,
		.dq_label = "com.apple.root.user-initiated-qos",
		.dq_serialnum = 12,
	),
	_DISPATCH_ROOT_QUEUE_ENTRY(USER_INITIATED, DISPATCH_PRIORITY_FLAG_OVERCOMMIT,
		.dq_label = "com.apple.root.user-initiated-qos.overcommit",
		.dq_serialnum = 13,
	),
	_DISPATCH_ROOT_QUEUE_ENTRY(USER_INTERACTIVE, 0,
		.dq_label = "com.apple.root.user-interactive-qos",
		.dq_serialnum = 14,
	),
	_DISPATCH_ROOT_QUEUE_ENTRY(USER_INTERACTIVE, DISPATCH_PRIORITY_FLAG_OVERCOMMIT,
		.dq_label = "com.apple.root.user-interactive-qos.overcommit",
		.dq_serialnum = 15,
	),
};

主队列

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
struct dispatch_queue_static_s _dispatch_main_q = {
	DISPATCH_GLOBAL_OBJECT_HEADER(queue_main),
#if !DISPATCH_USE_RESOLVERS
	.do_targetq = _dispatch_get_default_queue(true),
#endif
	.dq_state = DISPATCH_QUEUE_STATE_INIT_VALUE(1) |
			DISPATCH_QUEUE_ROLE_BASE_ANON,
	.dq_label = "com.apple.main-thread",
	.dq_atomic_flags = DQF_THREAD_BOUND | DQF_WIDTH(1),
	.dq_serialnum = 1,
};

#define _dispatch_get_default_queue(overcommit) \
		_dispatch_root_queues[DISPATCH_ROOT_QUEUE_IDX_DEFAULT_QOS + \
				!!(overcommit)]._as_dq

管理队列

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
struct dispatch_queue_global_s _dispatch_mgr_root_queue = {
	DISPATCH_GLOBAL_OBJECT_HEADER(queue_global),
	.dq_state = DISPATCH_ROOT_QUEUE_STATE_INIT_VALUE,
	.do_ctxt = &_dispatch_mgr_root_queue_pthread_context,
	.dq_label = "com.apple.root.libdispatch-manager",
	.dq_atomic_flags = DQF_WIDTH(DISPATCH_QUEUE_WIDTH_POOL),
	.dq_priority = DISPATCH_PRIORITY_FLAG_MANAGER |
			DISPATCH_PRIORITY_SATURATED_OVERRIDE,
	.dq_serialnum = 3,
	.dgq_thread_pool_size = 1,
};



struct dispatch_queue_static_s _dispatch_mgr_q = {
	DISPATCH_GLOBAL_OBJECT_HEADER(queue_mgr),
	.dq_state = DISPATCH_QUEUE_STATE_INIT_VALUE(1) |
			DISPATCH_QUEUE_ROLE_BASE_ANON,
	.do_ctxt = (void *)-1,
	.do_targetq = _dispatch_mgr_root_queue._as_dq,
	.dq_label = "com.apple.libdispatch-manager",
	.dq_atomic_flags = DQF_WIDTH(1),
	.dq_priority = DISPATCH_PRIORITY_FLAG_MANAGER |
			DISPATCH_PRIORITY_SATURATED_OVERRIDE,
	.dq_serialnum = 2,
};

可以看到，无论是主队列，管理队列，还是自定义队列，都使用root queue作为target queue

Target Queue

Darget queue 是队列任务最终执行的地方。但是全局队列没有设置target queue (do_targetq)。同时值得注意的是，targetQueue才是提交的block执行的关键

The target queue determines whether the block will be invoked serially or concurrently with respect to other blocks submitted to that same queue.Serial queues are processed concurrently with respect to each other.

QOS

在设置队列优先级的时候会涉及到QOS的设置。QOS是自iOS8后新引入的特性。主要包含以下五种：

  • NSQualityOfServiceUserInteractive
    用户交互相关，通常和UI相关。

  • NSQualityOfServiceUserInitiated
    由用户发起且需要立即完成的任务

  • NSQualityOfServiceUtility
    需要花费一些时间，不是马上需要结果的任务

  • NSQualityOfServiceBackground
    后台任务

  • NSQualityOfServiceDefault
    默认优先级，介于NSQualityOfServiceUserInteractive 和 NSQualityOfServiceUtility 之间，在没有QOS信息时默认使用
    队列优先级和QOS类之间的映射关系如下

    1
    2
    3
    4
    DISPATCH_QUEUE_PRIORITY_HIGH:         QOS_CLASS_USER_INITIATED
    DISPATCH_QUEUE_PRIORITY_DEFAULT:      QOS_CLASS_DEFAULT
     DISPATCH_QUEUE_PRIORITY_LOW:          QOS_CLASS_UTILITY
    DISPATCH_QUEUE_PRIORITY_BACKGROUND:   QOS_CLASS_BACKGROUND

Overcommit

overcommit 参数表示队列在执行blokc时，无论多忙都会新开一个线程

The queue will create a new thread for invoking blocks, regardless of how
busy the computer is.

在root queue我们也可以看到overcommit的身影。值得注意的是全局队列和自定义并发队列是非overcommit的，而主队列和自定义串行队列的都是overcommit的。当我们使用dispatch_async提交任务到串行队列，由于串行队列一般是overcommit的，所以会创建一个新的线程，而并发队列是非overcommit的，所以不会创建新的线程，而是从底层的线程池中获取。

即便如此，队列在同步执行任务时是不会创建新的线程的，所有的任务都会在当前的线程中执行，且会阻塞线程。dispatch_sync底层使用信号量来实现串行

任务提交

我们提交的block任务，经过GCD底层封装之后，被存储于队列的链表中，符合FIFO原则。
只有提交到主队列的任务是在主线程中执行，因为其内部线程是和队列绑定的。主队列的任务由Runloop处理，但是分发到其他队列的任务由底层的线程池处理

API深入

dispatch_sync

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
DISPATCH_NOINLINE
void
dispatch_sync(dispatch_queue_t dq, dispatch_block_t work)
{
	uintptr_t dc_flags = DC_FLAG_BLOCK;


	if (unlikely(_dispatch_block_has_private_data(work))) {
		return _dispatch_sync_block_with_privdata(dq, work, dc_flags);
	}
	_dispatch_sync_f(dq, work, _dispatch_Block_invoke(work), dc_flags);
}
#endif // __BLOCKS__


DISPATCH_NOINLINE
static void
_dispatch_sync_f(dispatch_queue_t dq, void *ctxt, dispatch_function_t func,
		uintptr_t dc_flags)
{
	_dispatch_sync_f_inline(dq, ctxt, func, dc_flags);
}


DISPATCH_ALWAYS_INLINE
static inline void
_dispatch_sync_f_inline(dispatch_queue_t dq, void *ctxt,
		dispatch_function_t func, uintptr_t dc_flags)
{
	// 串行会走到这里
	// dispatch queue 的width
	if (likely(dq->dq_width == 1)) {
		return _dispatch_barrier_sync_f(dq, ctxt, func, dc_flags);
	}

	// 并发走下面
	if (unlikely(dx_metatype(dq) != _DISPATCH_LANE_TYPE)) {
		DISPATCH_CLIENT_CRASH(0, "Queue type doesn't support dispatch_sync");
	}

	dispatch_lane_t dl = upcast(dq)._dl;
	// 全局并发队列和 绑定了 非派发线程的队列 会走 _dispatch_sync_f_slow
	// Global concurrent queues and queues bound to non-dispatch threads
	// always fall into the slow case, see DISPATCH_ROOT_QUEUE_STATE_INIT_VALUE
	if (unlikely(!_dispatch_queue_try_reserve_sync_width(dl))) {
		return _dispatch_sync_f_slow(dl, ctxt, func, 0, dl, dc_flags);
	}

	// 找到最终的target queue
	if (unlikely(dq->do_targetq->do_targetq)) {
		return _dispatch_sync_recurse(dl, ctxt, func, dc_flags);
	}

	// 开始执行方法
	_dispatch_introspection_sync_begin(dl);
	// 执行block
	_dispatch_sync_invoke_and_complete(dl, ctxt, func DISPATCH_TRACE_ARG(
	_dispatch_trace_item_sync_push_pop(dq, ctxt, func, dc_flags)));
}



DISPATCH_NOINLINE
static void
_dispatch_barrier_sync_f(dispatch_queue_t dq, void *ctxt,
		dispatch_function_t func, uintptr_t dc_flags)
{
	_dispatch_barrier_sync_f_inline(dq, ctxt, func, dc_flags);
}



DISPATCH_ALWAYS_INLINE
static inline void
_dispatch_barrier_sync_f_inline(dispatch_queue_t dq, void *ctxt,
		dispatch_function_t func, uintptr_t dc_flags)
{
	dispatch_tid tid = _dispatch_tid_self();

	if (unlikely(dx_metatype(dq) != _DISPATCH_LANE_TYPE)) {
		DISPATCH_CLIENT_CRASH(0, "Queue type doesn't support dispatch_sync");
	}

	dispatch_lane_t dl = upcast(dq)._dl;
	// The more correct thing to do would be to merge the qos of the thread
	// that just acquired the barrier lock into the queue state.
	//
	// However this is too expensive for the fast path, so skip doing it.
	// The chosen tradeoff is that if an enqueue on a lower priority thread
	// contends with this fast path, this thread may receive a useless override.
	//
	// Global concurrent queues and queues bound to non-dispatch threads
	// always fall into the slow case, see DISPATCH_ROOT_QUEUE_STATE_INIT_VALUE
	if (unlikely(!_dispatch_queue_try_acquire_barrier_sync(dl, tid))) {
		return _dispatch_sync_f_slow(dl, ctxt, func, DC_FLAG_BARRIER, dl,
				DC_FLAG_BARRIER | dc_flags);
	}

	if (unlikely(dl->do_targetq->do_targetq)) {
		return _dispatch_sync_recurse(dl, ctxt, func,
				DC_FLAG_BARRIER | dc_flags);
	}
	_dispatch_introspection_sync_begin(dl);
	_dispatch_lane_barrier_sync_invoke_and_complete(dl, ctxt, func
			DISPATCH_TRACE_ARG(_dispatch_trace_item_sync_push_pop(
					dq, ctxt, func, dc_flags | DC_FLAG_BARRIER)));
}



/*
 * For queues we can cheat and inline the unlock code, which is invalid
 * for objects with a more complex state machine (sources or mach channels)
 */
 // block执行
DISPATCH_NOINLINE
static void
_dispatch_lane_barrier_sync_invoke_and_complete(dispatch_lane_t dq,
		void *ctxt, dispatch_function_t func DISPATCH_TRACE_ARG(void *dc))
{
	_dispatch_sync_function_invoke_inline(dq, ctxt, func);
	_dispatch_trace_item_complete(dc);
	if (unlikely(dq->dq_items_tail || dq->dq_width > 1)) {
		return _dispatch_lane_barrier_complete(dq, 0, 0);
	}

	// Presence of any of these bits requires more work that only
	// _dispatch_*_barrier_complete() handles properly
	//
	// Note: testing for RECEIVED_OVERRIDE or RECEIVED_SYNC_WAIT without
	// checking the role is sloppy, but is a super fast check, and neither of
	// these bits should be set if the lock was never contended/discovered.
	const uint64_t fail_unlock_mask = DISPATCH_QUEUE_SUSPEND_BITS_MASK |
			DISPATCH_QUEUE_ENQUEUED | DISPATCH_QUEUE_DIRTY |
			DISPATCH_QUEUE_RECEIVED_OVERRIDE | DISPATCH_QUEUE_SYNC_TRANSFER |
			DISPATCH_QUEUE_RECEIVED_SYNC_WAIT;
	uint64_t old_state, new_state;

	// similar to _dispatch_queue_drain_try_unlock
	os_atomic_rmw_loop2o(dq, dq_state, old_state, new_state, release, {
		new_state  = old_state - DISPATCH_QUEUE_SERIAL_DRAIN_OWNED;
		new_state &= ~DISPATCH_QUEUE_DRAIN_UNLOCK_MASK;
		new_state &= ~DISPATCH_QUEUE_MAX_QOS_MASK;
		if (unlikely(old_state & fail_unlock_mask)) {
			os_atomic_rmw_loop_give_up({
				return _dispatch_lane_barrier_complete(dq, 0, 0);
			});
		}
	});
	if (_dq_state_is_base_wlh(old_state)) {
		_dispatch_event_loop_assert_not_owned((dispatch_wlh_t)dq);
	}
}


DISPATCH_ALWAYS_INLINE
static inline void
_dispatch_sync_function_invoke_inline(dispatch_queue_class_t dq, void *ctxt,
		dispatch_function_t func)
{
	dispatch_thread_frame_s dtf;
	_dispatch_thread_frame_push(&dtf, dq);
	_dispatch_client_callout(ctxt, func);
	_dispatch_perfmon_workitem_inc();
	_dispatch_thread_frame_pop(&dtf);
}

dispatch_async

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
void
dispatch_async(dispatch_queue_t dq, dispatch_block_t work)
{
	dispatch_continuation_t dc = _dispatch_continuation_alloc();
	uintptr_t dc_flags = DC_FLAG_CONSUME;
	dispatch_qos_t qos;

	qos = _dispatch_continuation_init(dc, dq, work, 0, dc_flags);
	_dispatch_continuation_async(dq, dc, qos, dc->dc_flags);
}


DISPATCH_ALWAYS_INLINE
static inline void
_dispatch_continuation_async(dispatch_queue_class_t dqu,
		dispatch_continuation_t dc, dispatch_qos_t qos, uintptr_t dc_flags)
{
#if DISPATCH_INTROSPECTION
	if (!(dc_flags & DC_FLAG_NO_INTROSPECTION)) {
		_dispatch_trace_item_push(dqu, dc);
	}
#else
	(void)dc_flags;
#endif
	return dx_push(dqu._dq, dc, qos);
}


#define dx_push(x, y, z) dx_vtable(x)->dq_push(x, y, z)



// 这里有一系列的实例模版
DISPATCH_VTABLE_INSTANCE(queue,
	// This is the base class for queues, no objects of this type are made
	.do_type        = _DISPATCH_QUEUE_CLUSTER,
	.do_dispose     = _dispatch_object_no_dispose,
	.do_debug       = _dispatch_queue_debug,
	.do_invoke      = _dispatch_object_no_invoke,

	.dq_activate    = _dispatch_queue_no_activate,
);

DISPATCH_VTABLE_INSTANCE(workloop,
	.do_type        = DISPATCH_WORKLOOP_TYPE,
	.do_dispose     = _dispatch_workloop_dispose,
	.do_debug       = _dispatch_queue_debug,
	.do_invoke      = _dispatch_workloop_invoke,

	.dq_activate    = _dispatch_queue_no_activate,
	.dq_wakeup      = _dispatch_workloop_wakeup,
	.dq_push        = _dispatch_workloop_push,
);

DISPATCH_VTABLE_SUBCLASS_INSTANCE(queue_serial, lane,
	.do_type        = DISPATCH_QUEUE_SERIAL_TYPE,
	.do_dispose     = _dispatch_lane_dispose,
	.do_debug       = _dispatch_queue_debug,
	.do_invoke      = _dispatch_lane_invoke,

	.dq_activate    = _dispatch_lane_activate,
	.dq_wakeup      = _dispatch_lane_wakeup,
	.dq_push        = _dispatch_lane_push,
);

DISPATCH_VTABLE_SUBCLASS_INSTANCE(queue_concurrent, lane,
	.do_type        = DISPATCH_QUEUE_CONCURRENT_TYPE,
	.do_dispose     = _dispatch_lane_dispose,
	.do_debug       = _dispatch_queue_debug,
	.do_invoke      = _dispatch_lane_invoke,

	.dq_activate    = _dispatch_lane_activate,
	.dq_wakeup      = _dispatch_lane_wakeup,
	.dq_push        = _dispatch_lane_concurrent_push,
);

DISPATCH_VTABLE_SUBCLASS_INSTANCE(queue_global, lane,
	.do_type        = DISPATCH_QUEUE_GLOBAL_ROOT_TYPE,
	.do_dispose     = _dispatch_object_no_dispose,
	.do_debug       = _dispatch_queue_debug,
	.do_invoke      = _dispatch_object_no_invoke,

	.dq_activate    = _dispatch_queue_no_activate,
	.dq_wakeup      = _dispatch_root_queue_wakeup,
	.dq_push        = _dispatch_root_queue_push,
);

#if DISPATCH_USE_PTHREAD_ROOT_QUEUES
DISPATCH_VTABLE_SUBCLASS_INSTANCE(queue_pthread_root, lane,
	.do_type        = DISPATCH_QUEUE_PTHREAD_ROOT_TYPE,
	.do_dispose     = _dispatch_pthread_root_queue_dispose,
	.do_debug       = _dispatch_queue_debug,
	.do_invoke      = _dispatch_object_no_invoke,

	.dq_activate    = _dispatch_queue_no_activate,
	.dq_wakeup      = _dispatch_root_queue_wakeup,
	.dq_push        = _dispatch_root_queue_push,
);
#endif // DISPATCH_USE_PTHREAD_ROOT_QUEUES

DISPATCH_VTABLE_SUBCLASS_INSTANCE(queue_mgr, lane,
	.do_type        = DISPATCH_QUEUE_MGR_TYPE,
	.do_dispose     = _dispatch_object_no_dispose,
	.do_debug       = _dispatch_queue_debug,
#if DISPATCH_USE_MGR_THREAD
	.do_invoke      = _dispatch_mgr_thread,
#else
	.do_invoke      = _dispatch_object_no_invoke,
#endif

	.dq_activate    = _dispatch_queue_no_activate,
	.dq_wakeup      = _dispatch_mgr_queue_wakeup,
	.dq_push        = _dispatch_mgr_queue_push,
);

DISPATCH_VTABLE_SUBCLASS_INSTANCE(queue_main, lane,
	.do_type        = DISPATCH_QUEUE_MAIN_TYPE,
	.do_dispose     = _dispatch_lane_dispose,
	.do_debug       = _dispatch_queue_debug,
	.do_invoke      = _dispatch_lane_invoke,

	.dq_activate    = _dispatch_queue_no_activate,
	.dq_wakeup      = _dispatch_main_queue_wakeup,
	.dq_push        = _dispatch_main_queue_push,
);

#if DISPATCH_COCOA_COMPAT
DISPATCH_VTABLE_SUBCLASS_INSTANCE(queue_runloop, lane,
	.do_type        = DISPATCH_QUEUE_RUNLOOP_TYPE,
	.do_dispose     = _dispatch_runloop_queue_dispose,
	.do_debug       = _dispatch_queue_debug,
	.do_invoke      = _dispatch_lane_invoke,

	.dq_activate    = _dispatch_queue_no_activate,
	.dq_wakeup      = _dispatch_runloop_queue_wakeup,
	.dq_push        = _dispatch_lane_push,
);
#endif

DISPATCH_VTABLE_INSTANCE(source,
	.do_type        = DISPATCH_SOURCE_KEVENT_TYPE,
	.do_dispose     = _dispatch_source_dispose,
	.do_debug       = _dispatch_source_debug,
	.do_invoke      = _dispatch_source_invoke,

	.dq_activate    = _dispatch_source_activate,
	.dq_wakeup      = _dispatch_source_wakeup,
	.dq_push        = _dispatch_lane_push,
);

DISPATCH_VTABLE_INSTANCE(channel,
	.do_type        = DISPATCH_CHANNEL_TYPE,
	.do_dispose     = _dispatch_channel_dispose,
	.do_debug       = _dispatch_channel_debug,
	.do_invoke      = _dispatch_channel_invoke,

	.dq_activate    = _dispatch_lane_activate,
	.dq_wakeup      = _dispatch_channel_wakeup,
	.dq_push        = _dispatch_lane_push,
);

#if HAVE_MACH
DISPATCH_VTABLE_INSTANCE(mach,
	.do_type        = DISPATCH_MACH_CHANNEL_TYPE,
	.do_dispose     = _dispatch_mach_dispose,
	.do_debug       = _dispatch_mach_debug,
	.do_invoke      = _dispatch_mach_invoke,

	.dq_activate    = _dispatch_mach_activate,
	.dq_wakeup      = _dispatch_mach_wakeup,
	.dq_push        = _dispatch_lane_push,
);



// 比如 主队列
DISPATCH_NOINLINE
void
_dispatch_main_queue_push(dispatch_queue_main_t dq, dispatch_object_t dou,
		dispatch_qos_t qos)
{
	// Same as _dispatch_lane_push() but without the refcounting due to being
	// a global object
	if (_dispatch_queue_push_item(dq, dou)) {
		return dx_wakeup(dq, qos, DISPATCH_WAKEUP_MAKE_DIRTY);
	}

	qos = _dispatch_queue_push_qos(dq, qos);
	if (_dispatch_queue_need_override(dq, qos)) {
		return dx_wakeup(dq, qos, 0);
	}
}


// 唤醒runloop
void
_dispatch_main_queue_wakeup(dispatch_queue_main_t dq, dispatch_qos_t qos,
		dispatch_wakeup_flags_t flags)
{
#if DISPATCH_COCOA_COMPAT
	// 线程和队列绑定， 所有主队列走这里
	if (_dispatch_queue_is_thread_bound(dq)) {
		// 唤醒runloop
		return _dispatch_runloop_queue_wakeup(dq->_as_dl, qos, flags);
	}
#endif
	return _dispatch_lane_wakeup(dq, qos, flags);
}


// 比如全局队列
DISPATCH_NOINLINE
void
_dispatch_root_queue_push(dispatch_queue_global_t rq, dispatch_object_t dou,
		dispatch_qos_t qos)
{
#if DISPATCH_USE_KEVENT_WORKQUEUE
	dispatch_deferred_items_t ddi = _dispatch_deferred_items_get();
	if (unlikely(ddi && ddi->ddi_can_stash)) {
		dispatch_object_t old_dou = ddi->ddi_stashed_dou;
		dispatch_priority_t rq_overcommit;
		rq_overcommit = rq->dq_priority & DISPATCH_PRIORITY_FLAG_OVERCOMMIT;

		if (likely(!old_dou._do || rq_overcommit)) {
			dispatch_queue_global_t old_rq = ddi->ddi_stashed_rq;
			dispatch_qos_t old_qos = ddi->ddi_stashed_qos;
			ddi->ddi_stashed_rq = rq;
			ddi->ddi_stashed_dou = dou;
			ddi->ddi_stashed_qos = qos;
			_dispatch_debug("deferring item %p, rq %p, qos %d",
					dou._do, rq, qos);
			if (rq_overcommit) {
				ddi->ddi_can_stash = false;
			}
			if (likely(!old_dou._do)) {
				return;
			}
			// push the previously stashed item
			qos = old_qos;
			rq = old_rq;
			dou = old_dou;
		}
	}
#endif
#if HAVE_PTHREAD_WORKQUEUE_QOS
	if (_dispatch_root_queue_push_needs_override(rq, qos)) {
		return _dispatch_root_queue_push_override(rq, dou, qos);
	}
#else
	(void)qos;
#endif
	_dispatch_root_queue_push_inline(rq, dou, dou, 1);
}

dispatch_barrier

dispatch_once

dispatch_semaphore

dispatch_group

多线程应用

traget queue

dispatch_queue_set_specific/dispatch_get_specific

dispatch Source

dispatch Timer

dispatch_block_wait/dispatch_block_notify

dispatch_group_wait/dispatch_group_notify

一些问题

死锁场景

队列/线程关系及管理模型

注意事项

相关文献

赏

谢谢你请我喝咖啡☕️

支付宝
微信

扫一扫，分享到微信

微信分享二维码

tag:

    缺失模块。
    1、请确保node版本大于6.2
    2、在博客根目录（注意不是yilia根目录）执行以下命令：
    npm i hexo-generator-json-content --save

    3、在根目录_config.yml里添加配置：

      jsonContent:
    meta: false
    pages: false
    posts:
      title: true
      date: true
      path: true
      text: false
      raw: false
      content: false
      slug: false
      updated: false
      comments: false
      link: false
      permalink: false
      excerpt: false
      categories: false
      tags: true

很惭愧<br><br>只做了一点微小的工作<br>谢谢大家
